FIGURE 4 MED-WHT 10
OVER VIEW
A rigid white material for applications requiring biocompatibility and/or thermal resistance. It provides beautiful parts that can be sterilized and tested at high temperatures, over 100 °C.
A rigid white material for applications requiring biocompatibility and/or thermal resistance. It provides beautiful parts that can be sterilized and tested at high temperatures, over 100 °C.
. General medical applications requiring biocompatibility, sterilization, and/or thermal resistance
. Surgical drill guides, splints Bone models
. Parts requiring rigidity with high temperature and/or water resistance
. Parts with high definition details
. Capable of meeting ISO 10993-5 and -10 standards for biocompatibility (cytotoxicity, sensitization, and irritation)
. Smooth surfaces for beautiful display models and prototypes
.High-temperature testing
. True-to-CAD accuracy and crisp feature detail
. Biocompatible*
. Sterilizable by autoclave
. Thermal resistance over 100 °C
. Excellent humidity/moisture resistance
. Rigid and white
The full suite of mechanical properties is given per ASTM and ISO standards where applicable. All parts are conditioned per ASTM recommended standards for a minimum of 40 hours at 23 °C, 50% RH. Material properties include physical and mechanical properties, as well as thermal.
Figure 4 technology prints parts that are isotropic in mechanical properties meaning the parts printed along either the XYZ axis will give similar results. Parts do not need to be oriented to get the highest mechanical properties, further improving the degree of freedom for part orientation for mechanical properties.
. Tensile strength, Ultimate: 60 MPa
. Elongation at break: 3%
. Flexural modulus: 3290 MPa
. Impact strength (notched Izod): 17 J/m
. Heat Deflection Temperature @ 0.45 MPa: 102 °C
. Water absorption (24 hour): 0.25%
