FIGURE 4® MED-AMB 10

OVERVIEW

Figure 4® MED-AMB 10 Is A Transparent, Stiff Material Used In A Variety Of Medical And Industrial Applications, Including Those Requiring Biocompatibility, Sterilization, And/Or Temperature Resistance In Conjunction With Fluid Flow Viewing. This Material Is Capable Of Satisfying The ISO 10993-5 And -10 Criteria For Biocompatibility (Cytotoxicity, Sensitization, And Irritation) And May Also Be Autoclave Sterilized. It Produces Very Accurate Components With Great Feature Resolution And Definition.

APPLICATIONS

• Guides for surgical drills and splints

• Parts needing stiffness and a strong resistance to heat
  • Manifolds for fluid handling
  • Testing at elevated temperatures

• Parts with fine detail
  • Assemblies with threads

• Visualization and simulations of fluid flow

BENEFITS

• Capable of satisfying the ISO 10993-5 & -10 biocompatibility criteria (cytotoxicity, sensitization and irritation)
• Excellent visualization for components that need examination of their intrinsic characteristics and performance
• Testing at elevated temperatures
• True-to-CAD precision and fine detail on features

FEATURES

• Biocompatible*
• Autoclave sterilizable
• Thermal conductivity more than 100 °C
• Excellent tolerance to humidity/moisture
• Inflexible and transparent

MATERIAL PROPERTIES

Where relevant, the complete set of mechanical characteristics is provided in accordance with ASTM and ISO standards. All components are conditioned for a minimum of 40 hours at 23 °C and 50% relative humidity in accordance with ASTM recommendations. Physical and mechanical qualities, as well as thermal properties, are all included in material properties.

ISOTROPIC PROPERTIES

Figure 4 technology creates isotropic components, which means that items printed along either the XYZ or Z axis will have equivalent mechanical qualities. Because parts do not need to be orientated to provide the best mechanical characteristics, the degree of freedom for part orientation for mechanical qualities is increased.
